Item # 4520

Clock Door Lock

Scroll down for additional Product Info and Size

Surface Lock

Product Info
  • Sold each
  • Supplied with one matching key.
  • Material: Steel
  • Finish: Bronze
  • Includes brass wood screws for mounting.
  • Keyhole-covers not-included as furniture style dictates keyhole-cover design
  • Insert Escutcheons: #0242, #0237 or #0253  can be used with this lock

  • Lock Size
    Measurement diagram below
  • Overall: 13/16" x 3"
  • Backset-Distance To Pin: 3/8"
  • Bolt Projection: 1/4"
  • Key: Barrel: 3/16" x 1-3/8", 2-5/16" Overall Length, Key-bit Height: 3/8"

  • Narrow Clock Door Locks are ideal for doors with slender stiles. Use on Curios, China cabinets and clock cases. Easy to install, simply surface mount. Attach with two screws to the back of the door. Bolt exits from either side for use on both right or left handed doors.

    This is a very reasonably priced clock door lock, as such: locking mechanism is average, not as smooth as finer made brass locks, yet is serviceable. Made in Asia.

    When replacing locks: Lock-backset must match keyhole-location in furniture. This is critical so that key can be inserted through door front into lock-keyhole. If these 2 measurements do-not match, it will not be possible to insert key through keyhole in door into lock.

    For help measuring and selecting full mortise locks, we recommend reading: How to select, measure and install full mortise cabinet locks.

    Surface Lock Measurement Diagram

    If Using Brass Wood Screws

    Care is required when installing brass screws. While these screws are the best match for most antique hardware however they are not as strong as steel screws. The screw is easily damaged if the hole is not properly prepared.

    The best practice is to first drill a pilot hole. Use a drill bit slightly smaller than the overall width of the screw, including threads, to drill the hole. Then use a steel screw, the same size as brass screw, to “cut threads” in pilot hole, by screwing steel screw into and then out of hole.
